ENGINE

SPECIAL FEATURES - TIGHTENING TORQUES ( m.daN )

Engines : RFS - VJX

SAXO

VJX

- Pre-tighten 0.4

- Tighten to 0.7

XSARA

RFS

- Pre-tighten 0.5

- Tighten to 1

TUD - XU

B1DP03BC B1DP01YD
