71
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT
XSARA
- Fit the drive belt.
- The tensioner roller (1).
- Tighten the screws (3) to 2 m.daN.
- Move the tensioner roller (1) using the tool (9.52 mm square drive (3/8)) at (2), in order to remove
the tool or locking peg (Ø 4 mm) at (4).
- Slowly release the tensioner roller (1) so that the roller (5) presses against the belt.
With air conditioning.
B1BP1HJC
Engines : LFX - RFS
