77
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT
Engines : WJZ - WJY
Power-assisted steering, without air conditioning (continued)
XSARA
Refitting.
- Refit the belt.
- Place the tool [1] on belt at "f".
WARNING : Position tool [1], with the knob downwards.
- tighten the nut (2) to obtain a value of :
Reused belt:
Keep the value taken at removal.
New belt:
Tension should be 110 SEEM units.
- Tighten the screw (1) to 9.5 m.daN.
- Check belt tension (tool [1].
Tension should be 144 ± 3 SEEM units.
- Remove the tool [1].
- Start the engine and run it for 10 seconds.
- Stop the engine.
- Place the tool [1] on the belt at "f".
- Tension should be 130 ± 4 SEEM units.
- Remove the tool [1].
B1BP1SJD
