Beforechangingafuse:
F thecauseofthefailuremustbeidentified
andrectified,
F allelectricalconsumersmustbeswitched
off,
F thevehiclemustbeimmobilisedwiththe
ignitionoff,
F identifythefailedfuseusingthetablesand
layoutdrawingsinthefollowingpages.
Changing a fuse
Good Failed
Thereplacementofafusenotshownin
thetablesbelowmaycauseaserious
malfunctionofyourvehicle.Contact
aCITROËNdealeroraqualified
workshop.
Tweezer
Changingafuse
Theextractiontweezerislocatedinthe
dashboardfuseboxcompartment.
Foraccesstoit:
F unclipthecoverbypullingatthetopright,
then left,
F disengagethecovercompletely,by
carefullypullinginthedirectionindicated
by the arrow,
F removethetweezer.
Access to the tools
Toreplaceafuse,youmust:
F usethespecialtweezertoextractthefuse
fromitshousingandchecktheconditionof
itsfilament.
F alwaysreplacethefailedfusewithafuseof
thesamerating(samecolour);usingafuse
ofadifferentratingcouldcausefaults(risk
offire).
Ifthefusefailsagainsoonafterreplacement,
havethevehicle'selectricalsystemcheckedby
aCITROËNdealeroraqualifiedworkshop.
