ENGINE
68
CHECKING AND SETTING THE VALVE TIMING
Engine : CFA
Tighten the 13 bolts and 2 nuts to the correct torque in the sequence indicated.
Tightening torque : 0,8 m.daN.
After tightening all the screws and nuts, check that "1" and "2" are tightened to the correct torque.
Refit the crankshaft position sensor.
WARNING: Do not use any component that has been dropped or knocked.
WARNING: Check the condition of the O-ring seal before refitting it.
Coat the O-ring seal with a thin layer of engine oil.
Refit the crankshaft position sensor with the screw.
Tightening torque : 0,8 m.daN.
Connect the connector of the crankshaft position sensor.
B1D202XD
B1D201QD
