73
ENGINE
CHECKING AND SETTING THE VALVE TIMING
Engine : 8HT
Remove the nut (17).
In the engine compartment
Move aside the header tank.
Support the engine with a roller jack equipped with a block.
Remove :
- the bottom support of the expansion chamber (20)
- the engine support (19)
- the intermediate engine support (18)
Lower the engine by 3 cm.
WARNING : Operate the jack with care. Do not leave the engine without support. Take care with
the routing of the header tank hose. Check for any interference between the lower crossmember
and the heat shield of the catalytic converter.
B1E2005D
B1B200GD
