XI
193
PRACTICAL INFORMATION
FUSEBOX C
Fuse N° Rating Function
F1 15 A Rear screen wipe (Tourer)
F2 30 A Locking and deadlocking relay
F3 5 A Airbags
F4 10 A Automatic gearbox - additional heater unit (Diesel) - electrochromatic rear view mirrors
F5 30 A Front window - sun roof - passenger door lighting - passenger door mirror adjustment
F6 30 A Rear window
F7 5 A Vanity mirror lighting - Glove box lighting - interior lamps - torch (Tourer)
F8 20 A
Radio - CD changer - Steering mounted controls - Screen - Defl ation detection -
Electric boot ECU
F9 30 A Cigarette lighter - front 12 V socket
F10 15 A Alarm - Steering mounted controls, lighting, signalling and wiper stalks
F11 15 A Low current anti-theft switch
F12 15 A
Driver’s electric seat - instrument panel - seat belt not fastened warning lamps -
air conditioning controls
F13 5 A
Engine relay unit - Hydraulic suspension pump cut-off relay -
airbag ECU supply
F14 15 A
Rain and sunshine sensor - parking sensors- passenger’s electric seat - trailer relay unit -
HIFI amplifi
er ECU - Bluetooth system - Lane Departure Warning System
F15 30 A Locking and deadlocking relay
F17 40 A Heated rear screen - heated door mirrors
FSH SHUNT PARK SHUNT
