CITROEN C6 2005 - Checking the Oil Pressure

76
ENGINE
CHECKING THE OIL PRESSURE
Engine ES9A DT17BTED4
Temperature (°C) 80°C
Pressure (bars) 2
Rpm 900
Pressure (bars) 5 1 to 4
Rpm 3000 2500
Pressure (bars)
Rpm
2279-T.Bis X
4103-T X
(-).1503.K X
4202-T X
NOTE: Oil pressure should be checked with the engine cold, after checking the oil level.
