CI Man u al Page 21
Power Loss
If the power goes out, the system will keep time for 24 hours or until the battery is depleted. If a power
outage of more than 24 hours occurs, the time of day will fl ash on and off which indicates the time of
day should be reset. The system will remember the rest. If a power outage lasts less then 24 hours and
the time of day fl ashes on and off, the time of day should be reset and the non rechargeable battery
replaced.
Error Message
If the word “ERROR” and a number are alternately fl ashing on the display contact the OEM for help.
This indicates that the valve was not able to function properly.
STEP 1US
RETURN TO NORMAL MODE
Salt Remaining or Adding Salt (not available for WS2 valves)
If the Low Salt Warning was activated in the last step of OEM Softener System Setup the following screens will be viewed in the
User Display.
Note: The salt used per regeneration setting can be set in increments of 0.05 Kg, but the Kg REMAINING screen will round up or
down to the closest whole number.
When adding salt to the brine tank (if the salt remaining feature is activated) the following steps must be completed:
Once the salt remaining has gone below the set point the display will automatically fl ash Salt Fill.
Step 1US – Press the NEXT button until SALT appears in the display. It does not matter if the SALT
display alternates with the Kg REMAINING display.
Step 2US – Press SET CLOCK.
Step 3US – Set Kg REMAINING: Use ▲ or ▼ to adjust the Kg remaining in the brine tank.
NOTE: Estimate the Kg of salt in the brine tank and add it to the amount of salt added to the brine
tank. The example at the left would indicate 100 Kg of salt being added to a brine tank that has 20
Kg remaining.
Step 4US – Press SET CLOCK or NEXT to exit Adding Salt.
STEP 2US
STEP 3US
STEP 4US
To Next Page
