4
Note. Smaller Nitrate removal units are in self
contained cabinets, these have
been assembled in the factory
and do not require any assembly.
(see note after 2.1)
2. Installation
Please observe the local regulations concerning the installation of your system. Check that
you have allowed space for access to the unit for possible future maintenance. This
installation may require plumbing work and will require an electrical outlet to be fitted near the
system. Only attempt this if you have the necessary skills.
2.1 Pre-installation checks
The area needs to be level, frost free, have access to electricity and an open drain. Check the
incoming water quality is within any parameters specified for that media (contact your
supplier). In addition to this check the incoming water pressure is between 2 and 8 bar
(preferably approx. 4 bar) and the water temperature is between 3ºC and 45ºC.
If your system is a small cabinet unit proceed to section 2.6
2.2 Fitting the Distribution System
Fit the bottom distribution system into the vessel – the bottom screen should been pre glued
to the riser tube (fig A.1) (smaller systems). Alternatively if the system uses bottom laterals
these need to be assembled inside the vessel (fig A.2), Move the vessel in its final position as
it will be difficult to move once the media has been added.
Fig A.1 Fig A.2
Fig A.3
