Clarion NP509 User Manual

14
x Selected location (Cursor):
(page 21)
The following controls help you modify the map view to suit your actual needs the best. Most of these
controls appear only if you tap the map once, and disappear after a few seconds of inactivity.
Action Button(s) Description
Moving the map No buttons
You can move the map into any direction. Tap the map
at any desired location. The point you hit on the map
moves to the center of the screen.
If GPS position is available and you have moved the
map, the
button appears. Tap this button to
return to the GPS position.
Opening/closing map
control buttons
Tap this button to show or hide the following map
control buttons:
x Zoom in/out
x Rotate left/right (3D map only)
x Tilt up/down (3D map only)
x Zoom preset buttons (2D map only)
x Tilt and zoom preset buttons (3D map only)
x Return to GPS position button
x Smart Zoom button
Zooming in and out
,
Changes how much of the map is displayed on the
screen.
Clarion Mobile Map uses high-quality vector maps that
let you see the map at various zoom levels, always
with optimized content. It always displays street names
and other text with the same font size, never upside-
down, and you only see the streets and objects that
you need.
Map scaling has different limits in 2D and in 3D map
view modes.
Tilting up and down
,
Changes the vertical view angle of the map in 3D
mode.
Rotating left and right
,
Changes the horizontal view angle of the map in 3D
mode.
When GPS position is available, Clarion Mobile Map
always rotates the map so its top faces your direction
of travel (Track-Up orientation). You can turn away
from Track-Up with these buttons.
If GPS position is available and you have rotated the
map, the
button appears. Tap this button to re-
enable the automatic map rotation.
