Clarion NX605 User Manual

NX605 61
English
Yellow
Black
Purple
Purple/Black
Red
Gray
Gray/Black
White
White/Black
Green
Green/Black
Blue/White
Orange/White
Blue
Grass-Green
Purple/White
Reverse gear lead
Parking brake lead
Auto antenna
Illumination
Amplifier turn-on lead
Rear left
Rear left
Front left
Front left
Front right
Front right
+12V accessory
Rear right
Rear right
Ground
+12V main power
See next description for how to connect the parking brake lead.
10. WIRE CONNECTION
Radio antenna jack
Microphone
GPS antenna
jack
Refer to the following
illustration.
Right
Left
Black
Black
Yellow
Red
White
Red
White
audio input
terminal
video output
terminal
SiriusXM-
Connect
Vehicle Tuner
terminal (sold
separately)
Rear
audio
output
terminal
Android
smartphone
External
Amplifier
Rear Monitor
Steering
wheel remote
control
terminal (sold
separately)
Rear Vision
Camera
terminal
Purple
Right
Left
Gray
Red
White
Front
audio
output
terminal
Subwoofer
output
terminal
(MONO 2ch)
Right
Left
Yellow
White
Right
Left
video input
terminal
Gray
iPod/iPhone
HDMI cable
(sold separately)
HDMI/MHL
conversion adapter
HDMI conversion cable
Black
Red
USB terminal
Lightning-Digital
AV adapter
(made by Apple Inc.)
HDMI cable
(sold separately)
Lightning cable
(supplied with iPod/iPhone)
or
* The device with 30-pin connector
can be connected with the CCA-
750 (sold separately).
