- 12 -PU-2354A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Note) Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
■ELECTRICAL PARTS LIST
Main PWB(B1) section
BL130 880-2088B FM/AM
C101 168-1022-55 1000pF
C102 168-1022-55 1000pF
C103 168-1022-55 1000pF
C104 184-1073-39 16V100μF
C130 183-1073-28 10V100μF
C131 168-1032-55 0.01μF
C132 168-4732-78 0.047μF
C133 183-1073-28 10V100μF
C134 168-1032-55 0.01μF
C135 168-1042-78 16V 0.1μF
C140 168-1022-55 1000pF
C141 168-1532-55 0.015μF
C143 168-8232-78 0.082μF
C144 183-4753-58 35V4.7μF
C145 168-1022-55 1000pF
C146 178-3342-78 0.33μF
C147 178-2242-78 0.22μF
C148 168-2232-55 0.022μF
C149 183-1073-28 10V100μF
C150 168-1042-78 16V 0.1μF
C151 168-1042-78 16V 0.1μF
C152 183-2263-38 16V22μF
C153 168-1022-55 1000pF
C158 166-1511-50 150pF CH
C172 183-1073-28 10V100μF
C173 183-1073-28 10V100μF
C190 168-1042-78 16V 0.1μF
C191 168-1042-78 16V 0.1μF
C192 168-1042-78 16V 0.1μF
C193 168-1042-78 16V 0.1μF
C194 182-1073-33 16V100μF
C195 172-1041-15 0.1μF
C196 183-1063-38 16V10μF
C198 183-1073-28 10V100μF
C199 168-1032-55 0.01μF
C230 183-1073-28 10V100μF
C231 168-1032-55 0.01μF
C232 183-1073-28 10V100μF
C233 183-1073-28 10V100μF
C234 168-1032-55 0.01μF
C235 183-1073-28 10V100μF
C236 042-0505-84 10V33μF
C240 168-1022-55 1000pF
C250 183-1053-68 50V1μF
C251 183-1053-68 50V1μF
C252 178-2242-78 0.22μF
C253 178-2242-78 0.22μF
C254 168-4732-78 0.047μF
C255 168-1032-55 0.01μF
C256 183-2263-38 16V22μF
C257 166-3311-50 330pF CH
C258 166-1011-50 100pF CH
C259 166-1011-50 100pF CH
C260 166-1011-50 100pF CH
C261 166-1511-50 150pF CH
C262 166-3311-50 330pF CH
C263 183-1053-68 50V1μF
C264 168-1032-55 0.01μF
C265 168-1042-78 16V 0.1μF
C266 183-4753-58 35V4.7μF
C267 178-3342-78 0.33μF
C268 166-3311-50 330pF CH
C269 183-2263-38 16V22μF
C270 183-1073-28 10V100μF
C271 166-1201-50 12pF CH
C272 168-1042-78 16V 0.1μF
C273 166-1201-50 12pF CH
C274 168-2232-55 0.022μF
C276 168-1032-55 0.01μF
C277 176-2221-50 2200pF CH
C278 168-1032-55 0.01μF
C279 176-2221-50 2200pF CH
C280 168-1032-55 0.01μF
C282 183-2263-38 16V22μF
C283 168-1032-55 0.01μF
C284 176-2221-50 2200pF CH
C285 183-2263-38 16V22μF
C286 168-1032-55 0.01μF
C287 176-2221-50 2200pF CH
C288 178-3342-78 0.33μF
C289 168-1032-55 0.01μF
C290 168-1032-55 0.01μF
C291 178-2242-78 0.22μF
C292 178-3342-78 0.33μF
C293 178-3342-78 0.33μF
C294 168-1032-55 0.01μF
C295 178-3342-78 0.33μF
C310 183-1073-28 10V100μF
C311 168-1042-78 16V 0.1μF
C312 183-1053-68 50V1μF
C313 042-0427-94 16V47μF TAN
C330 183-1063-38 16V10μF
C331 183-1063-38 16V10μF
C332 183-1063-38 16V10μF
C333 183-1063-38 16V10μF
C334 183-1073-28 10V100μF
C337 168-3312-55 330pF
C338 168-3312-55 330pF
C350 178-1042-78 0.1μF
C351 172-1041-15 0.1μF
C352 184-2273-39 16V220μF
C353 042-0623-00 16V3300μF
C354 183-1053-68 50V1μF
C355 172-3341-15 0.33μF
C356 172-3341-15 0.33μF
C357 172-3341-15 0.33μF
C358 172-3341-15 0.33μF
C370 168-2232-55 0.022μF
C371 183-2253-68 50V2.2μF
C380 183-1063-38 16V10μF
C381 183-1063-38 16V10μF
C400 166-1601-50 16pF
C401 166-1601-50 16pF
C402 168-1032-55 0.01μF
C403 168-1042-78 16V 0.1μF
C404 184-3383-12 6.3V3300μF
C405 168-4732-78 0.047μF
C406 168-1042-78 16V 0.1μF
C407 166-1011-50 100pF CH
C409 168-3312-55 330pF
C410 168-3312-55 330pF
C411 168-1042-78 16V 0.1μF
C412 168-3322-55 3300pF
C413 168-3322-55 3300pF
C414 168-3322-55 3300pF
C415 168-3322-55 3300pF
C417 168-1222-55 1200pF
C419 168-1222-55 1200pF
C430 168-1032-55 0.01μF
C431 183-1053-68 50V1μF
C432 042-0427-94 16V47μF TAN
C433 172-1031-15 0.01μF
C434 172-1031-15 0.01μF
C435 184-2273-49 25V220μF
C436 182-1063-59 35V10μF
C450 168-1032-55 0.01μF
C460 168-2232-55 0.022μF
C480 168-1032-55 0.01μF
C481 168-1032-55 0.01μF
C490 184-2273-39 16V220μF
C586 166-2201-50 22pF CH
C720 168-1032-55 0.01μF
C799 184-1073-39 16V100μF
D100 001-0516-90 MA111
D101 001-0466-90 S5688B
D102 001-0466-90 S5688B
D140 001-0541-90 MA157
D142 001-0541-90 MA157
D170 001-4305-25 UDZSTE-17 9.1B
D170 001-4302-25 UDZTE-17 9.1B
D190 001-4301-43 HZU8.2B1
D191 001-4305-26 UDZSTE-17 10B
D191 001-4302-26 UDZTE-17 10B
D192 001-4301-48 HZU 9.1B3
D193 001-0516-90 MA111
D230 001-4305-20 UDZSTE-17 5.6B
D230 001-4302-20 UDZTE-17 5.6B
D231 001-4301-46 HZU 9.1B1
D232 001-0516-90 MA111
D250 001-0516-90 MA111
D251 001-0516-90 MA111
D311 001-4305-20 UDZSTE-17 5.6B
D311 001-4302-20 UDZTE-17 5.6B
D330 001-4305-20 UDZSTE-17 5.6B
D330 001-4302-20 UDZTE-17 5.6B
D370 001-0655-90 1SS294
D430 001-0466-90 S5688B
D431 001-4301-68 HZU18B1
D432 001-0502-90 1FWJ43
D434 001-0466-90 S5688B
D461 001-4305-19 UDZSTE-17 5.1B
D461 001-4302-19 UDZTE-17 5.1B
D480 001-4301-68 HZU18B1
D490 001-0516-90 MA111
D584 001-4306-10 UZU5BLL-TRF
IC140 051-0350-93 NJM4558M
IC190 051-1014-08 TA7291F
IC250 051-6357-08 SAA7704H
IC310 051-3273-90 L88M33TL
IC330 051-0267-08 TC4066BF
IC331 051-0350-93 NJM4558M
IC350 051-2036-00 TDA7454
IC380 051-2802-90 TDA7476
IC400 052-3156-90 MB90F594APF-G
IC430 051-5405-08 S-80723AN-DL
IC431 051-3272-90 TDA3606AT
IC432 051-5405-08 S-80723AN-DL
IC450 051-9415-58 BR93LG66F-WE2
IC480 051-5405-08 S-80723AN-DL
L100 010-6009-81 56μH
L101 010-6009-68 4.7μH
L102 010-2334-00 8.2mH
L103 010-2003-03 76μH
L140 010-2047-94 1mH
L250 010-6009-68 4.7μH
L251 010-6009-84 100μH
L252 010-2199-59 0.56μH J
L401 010-2199-74 10μH J
P190 076-0433-20 20P
P230 076-0640-18 18P
P400 076-0540-20 20P
P401 076-0570-07 7P
P402 076-0570-03 3P
Q100 190-1162-00 2SA1162
Q101 190-1162-00 2SA1162
Q102 192-3113-00 2SC3113
Q103 125-2020-96 DTC143ZK
Q103 125-2004-96 RN1406
Q104 192-2412-00 2SC2412
Q104 192-2712-00 2SC2712-OYGL
Q105 125-2020-96 DTC143ZK
Q105 125-2004-96 RN1406
