- 16 -PU-2354A
Sensor PWB(B5) section:CD mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Q101 060-0252-01 PT4850F
Q102 060-0252-01 PT4850F
Q103 060-0252-01 PT4850F
Chucking switch PWB(B6) section:CD mechanism
REF No. PART No. DESCRIPTION
S2 013-3879-01 SPPB12
Limit Switch PWB(B7) section:CD mechanism
REF No. PART No. DESCRIPTION
S1 013-7100-00 SPPB11
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Side PWB(B8) section:Tape mechanism
C101 168-3312-55 330pF
C102 168-3312-55 330pF
C103 168-3312-55 330pF
C104 168-3312-55 330pF
C105 183-4763-17 6.3V47μF
C106 042-0552-92 10V68μF
C107 042-0552-92 10V68μF
C108 168-1232-55 0.012μF
C109 168-1232-55 0.012μF
C110 168-2222-55 2200pF
C111 178-2242-78 0.22μF
C112 183-1063-37 16V10μF
C113 183-2263-37 16V22μF
C114 183-4743-67 50V0.47μF
C115 183-4753-57 35V4.7μF
C116 183-4753-57 35V4.7μF
IC101 051-1546-10 BA3430S
J101 074-0881-08 8P
R101 119-1241-15 1/16W 120kΩ
R102 119-1241-15 1/16W 120kΩ
R103 119-1241-15 1/16W 120kΩ
R104 119-1241-15 1/16W 120kΩ
R105 119-7501-15 1/16W 75Ω
R106 119-7501-15 1/16W 75Ω
R107 119-1531-15 1/16W 15kΩ
R108 119-1131-15 1/16W 11kΩ
R109 119-3341-15 1/16W 330kΩ
R110 119-1531-15 1/16W 15kΩ
R111 119-1131-15 1/16W 11kΩ
R112 119-3341-15 1/16W 330kΩ
R113 119-1811-15 1/16W 180Ω
R114 119-1011-15 1/16W 100Ω
R115 119-2231-15 1/16W 22kΩ
R116 119-1031-15 1/16W 10kΩ
R117 119-1031-15 1/16W 10kΩ
R118 119-1031-15 1/16W 10kΩ
R9001 119-0000-05 1/16W 0Ω JW
R9002 119-0000-05 1/16W 0Ω JW
Rear PWB(B9) section:Tape mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
J3 076-0353-08 8P
J2 074-0978-20 20P
R19 111-5611-91 1/4WS 560Ω
SW3 013-3906-00 SPPB51
Bottom PWB(B10) section:Tape mechanism
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
IC2 051-1776-00 NJL5801K
SW1 013-3953-01 SPPB32
SW2 013-7300-00 MODE SWITCH
