pin 39: MCCWbk : O : Mechanism control.
pin 40: MCWbk : O : Mechanism control.
pin 41: LIMITbk : IN : Mechanism control.
pin 42: NFLOCKbk : O : Monitor terminal.
pin 43: NTLOCKbk : O : Monitor terminal.
pin 44: RESYbk : O : Monitor terminal.
pin 45: NU : - : Not in use.
pin 46: NU : - : Not in use.
pin 47: NU : - : Not in use.
pin 48: NU : - : Not in use.
pin 49: NU : - : Not in use.
pin 50: NU : - : Not in use.
pin 51: NU : - : Not in use.
pin 52: NU : - : Not in use.
pin 53: NU : - : Not in use.
pin 54: NU : - : Not in use.
pin 55: NRSTbk : O : Communication line with CD IC.
pin 56: DMUTEbk : O : Communication line with CD IC.
pin 57: MLDbk : O : Communication line with CD IC.
pin 58: MDATAbk : O : Communication line with CD IC.
pin 59: MCLKbk : O : Communication line with CD IC.
pin 60: STATbk : IN : Communication line with CD IC.
pin 61: GND : - : Ground.
pin 62: KEY0bk :IN : For the test.
pin 63: KEY1bk :IN : For the test.
pin 64: KEY2bk :IN : For the test.
■EXPLODED VIEW・PARTS LIST
Main section
1 940-7921-01 ESCUTCHEON ASSY 1
2 380-5513-00 KNOB 2
3 380-5495-00 KNOB 5
4 345-8518-00 RUBBER SWITCH 1
5 039-1801-00 SWITCH PWB 1
(WITHOUT COMPONENT)
6 331-2998-00 LCD COVER 1
7 379-0459-00 INDICATOR 1
8 335-6746-00 DIFFUSER 1
9 335-6383-00 ILLUMI-PLATE 1
10 001-7035-02 LED 3
11 335-6381-00 LCD-HOLDER 1
12 016-0022-00 ROTARY ENCODER 1
13 016-0021-00 ROTARY ENCODER 1
14 074-1059-76 OUTLET SOCKET(26P) 2
15 076-0567-03 PLUG(3P) 1
16 074-1151-20 OUTLET SOCKET(20P) 1
17 013-7104-00 SWITCH 1
18 076-0567-07 PLUG(7P) 1
19 716-0778-00 WAVE SCREW 12
20 722-0603-00 NUT 5
21 016-4155-00 VARIABLE RESISTOR 5
22 076-0540-08 PLUG(8P) 1
23 331-2997-00 VR-HOLDER 1
24 076-0570-07 PLUG(7P) 1
25 309-0761-01 FRONT PLATE 1
26 305-0299-00 SIDE PLATE 1
27 305-0300-02 SIDE PLATE(R) 1
28 750-3414-01 SIDE SPRING 2
29 304-0469-00 LOWER COVER 1
30 303-0476-00 UPPER COVER 1
31 930-0800-50 TAPE MECHANISM 1
32 929-0095-50 CD MECHANISM 1
33 331-2993-00 MECH-BRKT 1
34 331-2994-00 MECH-BRKT 1
35 076-0570-03 PLUG(3P) 1
36 039-1799-01 MAIN PWB 1
(WITHOUT COMPONENT)
37 331-2991-00 MECH-BRKT 1
38 331-2992-00 MECH-BRKT 1
39 331-2990-00 IC-HOLDER 1
40 051-2036-00 IC(TDA7454) 1
41 076-0641-10 PLUG(10P) 1
42 039-1800-00 CONNECTOR PWB 1
(WITHOUT COMPONENT)
43 331-2995-00 OUTLET HOLDER 1
44 074-1262-00 OUTLET SOCKET 1
45 331-3220-00 ANT-HOLDER 1
46 076-0641-16 PLUG(16P) 1
47 060-8021-06 AUTO FUSE(10A) 1
48 313-1797-02 HEAT SINK 1
49 290-7914-00 LABEL 1
50 290-7913-00 LABEL 1
51 286-9433-00 SETPLATE 1
52 290-7885-00 BAR CODE LABEL 1
53 714-2606-81 MACHINE SCREW(M2.6×6) 28
54 714-3006-40 MACHINE SCREW(M3×6) 4
55 714-2303-81 MACHINE SCREW(M2.3×3) 4
56 716-1573-00 SCREW 4
57 290-8022-00 GUIDE LABEL 1
58 076-0640-18 PLUG(18P) 1
59 074-1151-08 OUTLET SOCKET(8P) 1
60 001-7048-91 LED 20
61 092-4300-10 ANT-RECEPTACLE 1
62 092-4301-10 ANT-RECEPTACLE 1
63 076-0433-20 PLUG(20P) 1
64 076-0540-20 PLUG(20P) 1
65 076-0641-24 PLUG(24P) 1
66 076-0324-05 PLUG(5P) 1
67 345-7496-00 REAR HOLDER 1
68 001-7031-81 LED 15
69 880-2088B FM/AM TUNER 1
NO. PART NO. DESCRIPTION Q'TYNO. PART NO. DESCRIPTION Q'TY
