Clarion PU-2354A User Manual

- 14 -PU-2354A
Connector PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C335 182-1063-39 16V10μF
C336 182-1063-39 16V10μF
C520 168-1032-55 0.01μF
C541 166-1011-50 100pF CH
C560 168-1042-78 16V 0.1μF
C580 168-1032-55 0.01μF
C582 182-1063-59 35V10μF
C583 166-6801-50 68pF CH
C584 166-6801-50 68pF CH
C587 166-1011-50 100pF CH
C600 172-1041-15 0.1μF
C650 172-1041-15 0.1μF
C651 173-3321-19 3300pF J
C659 168-1022-55 1000pF
C660 168-1022-55 1000pF
C661 168-1022-55 1000pF
C662 168-1022-55 1000pF
C663 168-1022-55 1000pF
C664 168-1022-55 1000pF
C665 168-1022-55 1000pF
C666 168-1022-55 1000pF
D500 001-0516-90 MA111
D500 001-0517-90 1SS355
D520 001-4305-19 UDZSTE-17 5.1B
D520 001-4302-19 UDZTE-17 5.1B
D521 001-0466-90 S5688B
D522 001-0516-90 MA111
D522 001-0517-90 1SS355
D540 001-0502-90 1FWJ43
D580 001-4902-92 HZM27FA-TL
D650 001-0334-30 RL202
D651 001-0466-90 S5688B
IC560 051-0860-08 TC74HC14AF
IC580 051-6623-08 TJA1054T
J650 074-1262-00 CONNECTOR
P100 076-0324-05 5P
P651 076-0641-16 16P
P652 076-0641-24 24P
P653 076-0641-10 10P
Q500 190-1431-00 2SA1431
Q501 192-2412-00 2SC2412
Q501 192-2712-00 2SC2712-OYGL
Q540 192-2412-00 2SC2412
Q540 192-2712-00 2SC2712-OYGL
Q541 103-2012-00 2SD2012
Q580 192-2412-00 2SC2412
Q580 192-2712-00 2SC2712-OYGL
Q581 125-0014-96 DTA143ZK
Q581 125-0002-96 RN2406
Q582 192-2412-00 2SC2412
Q582 192-2712-00 2SC2712-OYGL
Q600 193-1858-00 2SD1858
R342 111-1011-94 1/4W 100Ω
R500 119-2231-15 1/16W 22kΩ
R501 111-2221-94 1/4W 2.2kΩ
R502 119-2231-15 1/16W 22kΩ
R520 119-4721-15 1/16W 4.7kΩ
R521 119-4731-15 1/16W 47kΩ
R540 111-6891-94 1/4W 6.8Ω
R541 111-1021-94 1/4W 1kΩ
R560 119-1041-15 1/16W 100kΩ
R561 119-1041-15 1/16W 100kΩ
R562 119-4721-15 1/16W 4.7kΩ
R563 119-4721-15 1/16W 4.7kΩ
R564 119-1021-15 1/16W 1kΩ
R565 119-1031-15 1/16W 10kΩ
R566 119-1031-15 1/16W 10kΩ
R580 119-3331-15 1/16W 33kΩ
R581 119-4731-15 1/16W 47kΩ
R582 119-2241-15 1/16W 220kΩ
R583 111-5611-94 1/4WS 560Ω
R584 111-5611-94 1/4WS 560Ω
R585 119-1031-15 1/16W 10kΩ
R586 119-1041-15 1/16W 100kΩ
R600 119-2231-15 1/16W 22kΩ
R601 119-1021-15 1/16W 1kΩ
R650 119-1021-15 1/16W 1kΩ
R651 119-2221-15 1/16W 2.2kΩ
R652 111-1021-94 1/4W 1kΩ
R653 116-3911-15 1/8W 390Ω
R654 116-3911-15 1/8W 390Ω
R655 116-3911-15 1/8W 390Ω
R656 116-3911-15 1/8W 390Ω
R799 114-1001-18 1W 10Ω
R1011 119-1021-15 1/16W 1kΩ
R1023 119-0000-05 1/16W 0Ω JW
R1024 119-0000-05 1/16W 0Ω JW
SUP100 060-0122-91 DSP-141N-S00B
SUP101 060-0122-91 DSP-141N-S00B
T650 009-0666-62 0.4mH
T651 009-0666-62 0.4mH
TH520 002-0311-90 4.7Ω
TH600 002-0311-90 4.7Ω
TH650 002-0310-90 0.5Ω
060-8021-06 FUSE 10A
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
Switch PWB(B3) section
C700 168-1042-78 16V 0.1μF
C701 168-1032-55 0.01μF
C702 168-1032-55 0.01μF
C703 168-1032-55 0.01μF
C704 168-1032-55 0.01μF
C705 168-1032-55 0.01μF
C706 168-2232-55 0.022μF
C707 168-2232-55 0.022μF
C708 166-1201-50 12pF CH
C709 166-1201-50 12pF CH
C710 166-1601-50 16pF
C711 166-1601-50 16pF
C714 168-1042-78 16V 0.1μF
C717 168-1042-78 16V 0.1μF
C719 042-0427-94 16V47μF TAN
C720 168-1032-55 0.01μF
C721 042-0595-56 6.3V47μF
C722 168-1042-78 16V 0.1μF
C723 168-1222-55 1200pF
C724 168-3322-55 3300pF
C800 168-1032-55 0.01μF
C801 168-1032-55 0.01μF
C802 168-1032-55 0.01μF
C803 168-1032-55 0.01μF
C804 168-1032-55 0.01μF
C820 168-1042-78 16V 0.1μF
C821 168-1042-78 16V 0.1μF
C822 168-1042-78 16V 0.1μF
C823 168-1042-78 16V 0.1μF
C824 168-1042-78 16V 0.1μF
C825 042-0595-70 35V4.7μF
C826 042-0595-70 35V4.7μF
C827 042-0595-70 35V4.7μF
D700 001-0516-90 MA111
D700 001-0517-90 1SS355
D701 001-0516-90 MA111
D701 001-0517-90 1SS355
D702 001-0516-90 MA111
D702 001-0517-90 1SS355
D703 001-0516-90 MA111
D703 001-0517-90 1SS355
D720 001-7031-81 VR1112H-22
D721 001-7031-81 VR1112H-22
D722 001-7031-81 VR1112H-22
D723 001-7048-91 RFR1112H-22-TR
D724 001-7048-91 RFR1112H-22-TR
D725 001-7048-91 RFR1112H-22-TR
D726 001-7048-91 RFR1112H-22-TR
D727 001-7048-91 RFR1112H-22-TR
D728 001-7031-81 VR1112H-22
D729 001-7031-81 VR1112H-22
D730 001-7031-81 VR1112H-22
D731 001-7048-91 RFR1112H-22-TR
D732 001-7031-81 VR1112H-22
D733 001-7048-91 RFR1112H-22-TR
D734 001-7048-91 RFR1112H-22-TR
D735 001-7048-91 RFR1112H-22-TR
D736 001-7048-91 RFR1112H-22-TR
D737 001-7048-91 RFR1112H-22-TR
D738 001-7048-91 RFR1112H-22-TR
D739 001-7048-91 RFR1112H-22-TR
D740 001-7048-91 RFR1112H-22-TR
D741 001-7048-91 RFR1112H-22-TR
D742 001-7048-91 RFR1112H-22-TR
D743 001-7048-91 RFR1112H-22-TR
D744 001-7031-81 VR1112H-22
D745 001-7031-81 VR1112H-22
D746 001-7031-81 VR1112H-22
D749 001-4305-21 UDZSTE-17 6.2B
D749 001-4302-21 UDZTE-17 6.2B
D751 001-0516-90 MA111
D751 001-0517-90 1SS355
D752 001-7048-91 RFR1112H-22-TR
D753 001-7048-91 RFR1112H-22-TR
D754 001-7031-81 VR1112H-22
D755 001-7031-81 VR1112H-22
D756 001-7035-02 LB3336-N.P
D757 001-7035-02 LB3336-N.P
D758 001-7035-02 LB3336-N.P
D759 001-7031-81 VR1112H-22
D760 001-7031-81 VR1112H-22
D762 001-7031-81 VR1112H-22
D790 001-7048-91 RFR1112H-22-TR
IC700 052-3157-90 MB90F583BPF-G
J700 074-1151-20 20P
J800 074-1151-08 8P
L701 010-2199-74 10μH J
P800 076-0540-08 8P
P801 076-0567-07 7P
P802 076-0567-03 3P
P803 074-1059-76 26P
P804 074-1059-76 26P
Q720 133-1766-00 2SD1766
Q721 192-2412-00 2SC2412
Q721 192-2712-00 2SC2712-OYGL
Q722 190-1162-00 2SA1162
Q723 192-2412-00 2SC2412
Q723 192-2712-00 2SC2712-OYGL
Q724 191-1123-00 2SB1123
Q790 192-2412-00 2SC2412
Q790 192-2712-00 2SC2712-OYGL
R700 119-1531-15 1/16W 15kΩ
R702 119-0000-05 1/16W 0Ω JW
R703 119-1031-15 1/16W 10kΩ
R704 119-1031-15 1/16W 10kΩ
R705 119-1031-15 1/16W 10kΩ
R706 119-1031-15 1/16W 10kΩ
R707 119-1031-15 1/16W 10kΩ
R708 119-1031-15 1/16W 10kΩ
R709 119-1031-15 1/16W 10kΩ
R710 119-1031-15 1/16W 10kΩ
