VX404
English
As an additional safety feature, the audio from camera with built-in
microphones can be heard through the VX404.
Note:
Ifthereversecableisconnectedcorrectlytothecar,theunitgoestocameramode
automaticallywhenthecarisinreverses.
If a monitor is installed in the rear zone
and connected to the rear zone AV
output, passengers in the back seat
can watch the DVD/iPod Video/AUX1/
AUX2 video separately from front
source.
1. Touch the button to access the front
source.
2. Touch the button to close the rear
source.
Multi-Zone Operation
Independent sources can be played
simultaneously on the unit. For
example, a FM/AM console can
be playback on the front screen
while DVD video is available to rear
passengers. But now can’t select
DVD video in front.
Access Rear-Zone
1. Touch the Rear button on Main
Menu to access the Rear Source.
2. Select a source to play.
Exit Rear-Zone
Touch the 2-Zone off button to close
the Rear Source.
Note:
1. If the source is selected as the front,
the source in rear can’t be selected.
2. If the source is selected as the rear,
the source in front can’t be selected.
3. Touch the Front button to access
the main menu but not close the Rear
Source.
DVD Video in Rear
1 -Option button
2 -Show Cursor keys
3 -Previous Chapter /Fast Backward
button
4 -Play/Pause button
5 -Next Chapter /Fast Forward button
6 -Elapsed playing time
7 -Menu List button
8 -Front/Rear button
17. REAR SOURCE OPERATIONS
12
1 2 3 4 5 6 7
8
