31
VX404
English
Cautions on Wiring
1. Be sure to turn the power o before wiring.
2. Be particularly careful where you route the wires.
Keep them well away from the engine, and exhaust pipe, etc. Heat may
damage the wires.
3. If the fuse should blow, check to see if the wiring is correct.
If a fuse is blown, replace it with a new one of the same amperage rating
as the original (15A FUSE).
4. To replace the fuse, remove the old fuse on the back of the unit and
insert the new one. (Figure 7)
NOTE:
There are various types of fuse holder. Do not let the battery side touch other metal parts.
Figure 7
Fuse (15A FUSE)
After the connection, fix the cord by a clamp or insulation
tape for protection.
Fuse holder
CAUTION
Note:
*1: Connecting the PHONE INTERRUPT terminal
The phone interrupt will mute the audio if the lead receives a negative or ground signal.
