10.SPECIFICATIONS
FM Tuner
Frequency Range: 87.9 MHz to 107.9 MHz
Usable Sensitivity: 9 dBf
50dB Quieting Sensitivity: 15 dBf
Alternate Channel Selectivity: 70 dB
Stereo Separation (1 kHz): 32 dB
Frequency Response ( 3 dB): 30 Hz to 15 kHz
AM Tuner
Frequency Range: 530 kHz to 1710 kHz
Usable Sensitivity: 28 dB V
DVD Player
System:
Digital Versatile Disc System with CDDA
capable
Usable discs:
DVD video disc, Compact disc
Frequency Response:
20 Hz to 20 kHz (CD) ( 1 dB)
Dynamic Range: 100 dB (1 kHz)
Distortion: 0.006%
Audio Amplifier
Maximum power output:
160 W (40 W 4)
Speaker impedance: 4 (4 to 8 allowable)
Input
Audio input:
130 60mVrms (High)
600 80mVrms (Mid)
840 100mVrms (Low)
(input impedance 10 k or greater)
Video input:
1.0 0.2 Vp-p (input impedance 75 )
Video Output
Video output:
1.0 0.2 Vp-p (output impedance 75 )
LCD Monitor
VX409 Screen Size: 6.5-inch wide type
141 mm Width 78 mm Height
Display method:
Transmission type TN liquid crystal display
Drive method: TFT (thin-film transistor)
active matrix driving
Pixels: 336,960 (480 3 (RGB) 234)
General
Power source voltage:
14.4 V DC (10.8 to 15.6 V allowable)
Ground: Negative
Current consumption: 4.0 A (1 W)
Auto Antenna Rated Current: 500 mA less
VX409 Dimensions of the Main Unit:
7" Width (178 mm) 3-15/16" Height
(100 mm) 6-1/2" Depth (165 mm)
VX409 Weight of the Main Unit: 2.8 kg
Dimensions of the Remote Control Unit:
2-1/8" Width (54 mm) 9/16" Height
(14 mm) 4-13/16" Depth (122 mm)
Weight of the Remote Control Unit:
50 g (including battery)
Note:
• Specifications comply with JEITA Standards.
• Specifications and design are subject to change
without notice for further improvement.
Power Output:
18 W RMS x 4 Channels at 4 Ω
and 1% THD+N
Signal to Noise Ratio:
76 dBA (reference: 1 W into 4 Ω)
VZ409 Screen Size: 7-inch wide type
153mm Width 87 mm Height
VZ409 Dimensions of the Main Unit:
7" Width (178 mm) 2" Height
(50 mm) 6-5/16" Depth (160 mm)
VZ409 Weight of the Main Unit: 2.15 kg
38
English
Owner’s manual
VX409/VZ409
