Page -14- Clarke
®
Operator's Manual (EN) - FUSION 20 / 20T
ACCESSORIES
ACCESSORIES
DESCRIPTION PART NO.
Burnishing Pads - Cases of 5
Natural Blend, Tan HS 20" 976352
Aqua 20" 976240
Natural Blend, White HS 20" 976327
Dust Bag - Package of 10 54195A
36V Clarke Battery Maint. System 53390A
TROUBLESHOOTING
Machine Vibration
1. Pad is not centered properly.
2. Defective pad. Replace
Swirl Marks
1. Pad is too aggressive for the floor finish.
2. Pad is dirty. Check and replace.
Reduced Running Time
1. Battern needs to be charged.
2. Batteries need water. Add just enough to cover the
plates in each cell. Then charge the batteries and
check the water level again.
Pad assist machine does not pull itself (FIG. 12)
For pad assist adjustment, follow the steps below (see
steps 1 - 6 in Figure 12):
1. Tip burnisher back as shown to gain access to the
pivot bracket.
2. Remove the dust bag.
3. Pull down on the dust skirt to gain access to the
adjustment hardware.
4. Lossen pivot bracket adjustment hardware and
pivot bolts and rotate bracket counterclockwise to
increase pad assist.
5. Pivot braket has slots to allow adjustment.
6. Adjust pivot bracket so pad is tipped down towards
the RH side of the machine to increase the pad
assist. Then retighten the adjustment hardware.
CAUTION!
Pad assist will vary depending on the aggressiveness
of pad and the floor finish. If the deck is angled too
much it could result in the pad burning the floor on the
RH side.
