Operator's Manual - FUSION 20 / 20T - 51 -
Clarke
®
Fusion 20T
Body Assemby Parts List 2/08
Clarke
®
Operator's Manual - FUSION 20 / 20T - 51 -
Ref. Part No. Description Qty.
1 79984A Label, Connection Dia. 1
2 42401A Diode, Asm. Contactor 1
3 41022A Diode, Avalanche Asm. 1
4 61905A Plate, Electrical 1
5 41042A Controller, I-Drive 36V Traverse 1
6 80380A Screw, 8-32 x 1 1/4" P.H. 2
7 41448B Breaker, 30A Circuit 1
8 41402C Breaker, 70A Circuit, Cntrl/Act. 1
9 980614 Washer, 1/4" Starlock Ext. 4
10 920208 Nut, 1/4-20 Hex 4
11 87200A Washer, Lock #8 4
12 920108 Nut, 8-32 4
13 71388A Label, Clarke 2
14 38739A Cover, Harness 1
15 85395A Screw, 1/4-20 x 1/2" P.H. 2
16 61598A Bracket, Cord Wrap 1
17 40740A Cord, Charger NEMA 1
18 84237A Screw, 10-32 x .50 P.H. 6
19 38740A Strap, Retention (Dust Bags) 1
20 30779A Cover, Lower 1
21 980651 Washer, 5/16 Flat 2
22 920224 Nut, 10-32 Hex 2
23 980603 Washer, #10 Lock Ext. Tooth 2
24 52548A Tab, 1/4" Screw 3
25 962957 Screw, 10-16 x 1/2 Self Tap 3
26 41039A Switch, Tilt 1
27 962350 Screw, 10-32 x .500 2
28 980652 Washer, 5/16 Lock 2
29 85811A Screw, 5/16-18 x 3/4 Hex Hd 2
30 962027 Screw, 8-32 x 1/2 P.H. 2
31 41007A Relay, Traverse Power 1
32 962823 Screw, 1/4-20 x 1/2 P.H. 4
33 41801A Contactor, Main 36V 2
34 61909A Cover, Front Elec. Plate 1
35 79985A Label, Belt Conn. 1
36 962822 Screw, 1/4-20 x 5/8 1
NI 41041A Harness, Power 20" Traverse 1
NI 41038A Harness, Logic 20" Traverse 1
NI 193951 Trim, 3" Flexible 1
NI = Not Illustrated
