Operator's Manual - FUSION 20 / 20T - 53 -
Clarke
®
Fusion 20
Frame Assembly Parts List 1/09
Ref. # Part No. Description Qty.
1 920148 Nut, 3/8-16 Hex Jam 1
2 61918A Base, Two Spring 1
3 980646 Waher, 1/4” Flat 3
4 80018A Screw, Shoulder 1/4” Dia. 1
5 87060A Insulating, Bushing 1
6 54698A Spring, Extension .420 x 2.39 Zinc 1
7 61903A Arm, Head Lift (Flat) 1
8 80376A Screw, 1/2-13 x 7 H.H.C.S. 1
9 980648 Washer, Flat 1/2 2
10 54453A Bushing, 3/8 x 1/2 Nominal 2
11 920365 Nut, 1/2-13 Nylock 1
12 980657 Washer, Lock 1/4 4
13 980205 Washer, .31 I.D. x 1.06 O.D. 6
14 962989 Screw, 1/4-20 x 1 1/2 P.H. 2
15 51143A Spring, 5.75 Compression 2
16 41036A Charger, Battery 36VDC/25A 1
17 85806A Screw, 1/4-20 x 3/4 Hex SZ 2
18 54768A Clamp, P 5/16 Steel 1
19 980652 Washer, 5/16 Lock 10
20 920208 Nut, 1/4-20 Hex 2
21 85700A Screw, 1/4-20 x 1 H.H. C.S. 1
22 980614 Washer, 1/4” Starlock Ext. 3
23 69639A Strap, Static 1
24 962244 Screw, 3/8-16 x .75 Hex 4
25 80375A Screw, 3/8-16 x 1 1/4 Hex Hd. 1
26 81104A Nut, 1/4” Nylock 1
27 57423A Retaining Ring, Ext. 2
28 87616A Washer, Flat 1 x .75 x .06 Nylon 2
29 962620 Screw, 5/16-24 x 3/4” Hex Hd. 2
30 54691A Wheel, 8” 2
31 980645 Washer, 3/8” S.A.E. Flat 4
32 170883 Washer, Lock 3/8” 4
33 920260 Nut, 3/8-16 Hex 5
34 61917A Weldment, Non-Traverse Axle 1
35 85811A Screw, 5/16-18 x 3/4 Hex Hd. 8
36 980651 Washer, 5/16 Flat 8
37 54454A Caster, 3 1/2 Front Swivel 2
38 61904A Mainframe, 20” 1
NI 193951 Trim, Vinyl Lock - 8.50” Long 1
NI = not illustrated
