Classeq Under Counter Range - User Manual
32
11. Warewasher Specifications
11.1 Dimensions
Model No.
C400
C500
A. Width (mm)
460
600
1.
Drain Wastewater Outlet Port
B. Depth - door closed (mm)
570
600
2.
Equipotential Bonding Stud
C. Height (mm) min/max
720/750
820/850
3.
Detergent Tube (Clear)
D. Depth - door open (mm)
910
990
4.
Rinse Aid Tube (Blue)
E. Height to open door (mm)
310
364
5.
Water Inlet Port
F. Entry Clear Height (mm)
312
352
6.
Mains Electrical Cable
11.2 Technical Data
Model No.
C400
C500
Model No.
C400
C500
Water supply
connection
G¾”
(¾”BSP)
G¾” (¾”BSP)
Voltage - option 2 (V)
220-240
/1N~/50Hz
220-240
/1N~/50Hz
Water pressure -
min (bar)
2.0
2.0
Power consumption
- option 2 (kW)
2.58kW
2.58kW
Water flow rate -
min (L/min)
4
4
Wash Tank element
rating (kW)
2.00
2.00
Water temperature
- min/max (°C)
4/55
4/55
Rinse Tank element
rating (kW)
6.00
6.00
Drain Pump Flow
rate (L/min)
18
20
Wash Tank capacity
(litres)
9.50
15.00
Drain height -
pumped (mm)
540
600
Rinse Tank capacity
(litres)
6.5
6.5
Drain size (mm)
Ø40
Ø40
Rinse water
consumption @3bar
(L/cycle)
3.00
3.00
Current - standard
(A)
30 (1ph)
30 (1ph)
Wash Tank
temperature (°C)
60
60
Voltage - standard
(V)
220-240
/1N~/50Hz
220-240
/1N~/50Hz
Dish - Rinse Tank
temperature (°C)
82
82
