Cleanware HT-E - ELECTRICAL REQUIREMENTS

4
07610-004-64-85-A
ELECTRICAL REQUIREMENTS
SPECIFICATIONS
All electrical ratings provided in this manual are for reference
only. Always refer to the machine data plate to get exact electrical
information for this machine. All electrical work performed on
machines should be done in accordance with applicable
local, state, territorial, and national codes. Work should only
be performed by qualied electricians and authorized service
agents.
Note that all electrical wiring used in the HT-E must be rated, at
a minimum, for 212 °F (100 °C), and that only copper conductors
must be used.
Where applicable, heating element amperage draws have been
adjusted for the assumed input voltage. The manufacturer
assumes incoming voltages will be either 208 or 230 Volts. Some
heating elements used in the machines are rated for other voltages,
such as 240 Volts and 480 Volts. Always verify the amperage
draw of the machine in operation when sizing circuit protection.
Available Electrical Characteristics:
• 208 V, 60 Hz, Single-phase
• 230 V, 60 Hz, Single-phase
VOLTS 208 230
PHASE 1 1
FREQ 60 60
WASH
MOTOR
AMPS
3.8 A 3.8 A
DRAIN
MOTOR
AMPS
0.3 A 0.3 A
RINSE
MOTOR
AMPS
1.8 A 1.8 A
WASH
HEATER
AMPS
15.2 A 16.8 A
BOOSTER
HEATER
AMPS
21.7 A 24.0 A
TOTAL
LOAD
25.8 A 27.8 A
MCA 26.8 A 28.8 A
MOP 30.0 A 30.0 A
NOTICE
i
HT-E
Electrical Characteristics
