07610-004-64-85-A
8
INSTRUCTIONS
INSTALLATION
CHEMICAL FEEDER
EQUIPMENT
PRIMING CHEMICAL
FEEDER PUMPS
WARNING! Some of the
chemicals used in
dishwashing might cause
chemical burns if they
come in contact with skin.
Wear protective gear when
handling these chemicals.
If any contact with skin
occurs, immediately
follow the treatment
instructions provided
with the chemicals.
The thermostats on this machine have been set at the factory. They should only be
adjusted by an authorized service agent.
If adjustments are necessary, click here for instructions.
The HT-E dishmachine is supplied with detergent and rinse-aid chemical feeder
pumps. The pumps have regulating screws to adjust the amount of chemicals being
dispensed. Locate the open ends of the chemical tubes and place each one in the
appropriate container. The tubes are labeled "Detergent" and "Rinse-Aid."
The bottom of chemical containers cannot be located any higher than 8” from the
oor. Chemical feeder pumps need priming when the machine is rst installed or if
the chemical lines have been removed and air was allowed to enter.
1. Verify that the proper chemical tube stiener inlet is in the proper container.
2. Use the prime buttons located on the control panel to prime each pump. The
buttons are clearly marked DETERGENT and RINSE-AID.
3. To prime the pumps:
• Detergent - hold the DETERGENT button down until detergent is seen
entering the wash tank.
• Rinse-aid - hold the RINSE AID button down for two minutes.
A level machine is important to prevent any damage to the machine during operation
and to ensure the best possible results. The machine comes equipped with adjustable
bullet feet which can be turned using a pair of pliers. Since this machine is an
undercounter machine, it should be leveled as close as possible to the machine's
location before it is pushed under the counter.
THERMOSTATS
!
WARNING
!
CAUTION
set
set
set
set
LEVELING
CAUTION! Water
must be in the sump
and wash tank before
chemicals are dispensed!
