12.20 Analog port card (MVX-A16)
Category
Measures / comments
Height
6 RU
Depth
300 mm
Audio Interface
16, bi-directional
Input Format
Balanced
Output Format
Balanced
Ground Isolation
None; expected at User Panel/Station
Analog port card outputs
Level
0 dBu nominal
Impedance
100 Ohms balanced
Frequency Response
30 Hz–22 kHz ± 3 dB
Distortion
<0.05 %, @ 0 dBu, 300 Hz to 10 kHz;
<0.1 %, @ 0 dBu, 100 Hz to 20 kHz
Analog port card inputs
Level
0 dBv nominal
Impedance
600 Ohms balanced
Frequency Response
30 Hz–22 kHz ± 3 dB
Distortion
<0.05 %, @ 0 dBu, 300 Hz to 10 kHz;
<0.1 %, @ 0 dBu, 100 Hz to 20 kHz
Table 45: Analog port card (MVX-A16)
12.21 Data interface: 16 bi-directional
Category
Measures / comments
Input Format
RS-422 @ 2400 to 19200 kb/s
Output Format
RS-422 @ 2400 to 19200 kb/s
Input Termination
100 ohm ± 10%
Output Termination
None; expected at User Panel
Isolation
None; expected at User Panel
Table 46: Data interface: 16 bi-directional
