Each rear connector panel associated with an E-QUE interface holds eleven RJ-45 ports:
• Eight ports for connection to wireless equipment.
• Two ports for DECT sync.
• One port for LAN connections.
Each rear connector panel associated with an IVC-32 interface holds eleven RJ-45 ports:
• Eight ports for connection to E1/T1 equipment (not used).
• Two ports for DECT sync (not used).
• One port for LAN connections, used for IP-enabled V-Series panels and Concert soft-
panels.
Each rear connector panel associated with an LMC-64 interface holds eleven RJ-45 ports:
• Eight ports for connection to E1/T1 equipment (not used).
• Two ports for DECT sync (not used).
• One port for LAN interface used for broadcasting audio levels to Production Maestro
Pro clients.
Each rear connector panel associated with an E-FIB interface holds two fiber ports (TXVRA
and TXVRB).
Tip: For detailed information about connecting the matrix to user panels, interface modules
and other devices, see
4 Installing the HX-Median.
72
Eclipse HX-Median User Guide
