Power-Up Screen
•
This screen is displayed only on power-up, first use de
-
fault, and factory default.
•
The 1
st
upper-right-corner number displays the base’s
software revision. The version number increments for
changes in operational software.
•
The 2
nd
upper-right-corner number displays the base’s
channel map (frequency plan) version. The version num
-
ber increments for changes in the channel map.
•
Once the power-up screen is displayed, it will change to
the operating screen after a few seconds.
Operating Screen
•
Screen is displayed after power-up screen.
•
System will revert to this screen if no activity is detected
on the LCD display buttons after 3 minutes.
•
Screen displays current status of the system.
Beltpack Activity Code Definitions:
6-5
Clear-Com
S
R
C60001
B40001
Group 03A
T1
4
R1
tx
On
Off
Tx
Tx
Operating Screen
2
3
Tx
no
no tx = No Beltpack Transmit Carrier Detected
Off = Receiver is not selected on front panel
Tx = Beltpack is on
Power-Up Screen
