Sequence of Operation
4-2
750-91 (revised 2009)
Model CB-LE Packaged Boiler Manual
4.2 — Circuit and Interlock Controls
The burner control circuit is a two-wire system designed for 115 Vac, 60 Hz, single-phase power.
The electrical portion of the boiler is made up of individual circuits with controls that are wired in a manner
designed to provide a safe workable system. The program relay provides connection points for the interconnection
of the various circuits.
The controls used vary depending upon the fuel oil or gas and the specific requirement of applicable regulatory
bodies. Refer to the boiler wiring diagram to determine the actual controls provided. The circuits and controls nor-
mally used in the circuits are identified in the following table and are referred to in Section 4.3.
Circuit Components
Limit Circuit
Burner switch (BS)
Operating limit control (OLC) - pressure or temperature
High limit control (HLC) - pressure or temperature
Low-water cutoff (LWCO)
Gas-oil selector switch (GOS) - combination burner only
Oil drawer switch (ODS) - oil burner
Low oil temperature switch (LOTS) - nos. 5 and 6 oil only
Low gas pressure switch (LGPS)
High gas pressure switch (HGPS)
LE proximity switch interlock
Fuel valve interlock circuit
Main gas valve auxiliary switch (MGVAS)
Oil valve auxiliary switch (OVAS)
Blower Motor Starter Circuit
Blower motor starter (BMS)
Air compressor motor starter (ACMS) - if provided
Air purge valve (APV) - nos. 5 and 6 oil only
Running Interlock Circuit
Blower motor starter interlock (BMSI)
Combustion air proving switch (CAPS)
Atomizing air proving switch (AAPS) - if provided
Low Fire Proving Circuit
Low fire switch (LFS)
Pilot Ignition Circuit
Gas pilot valve (GPV)
Ignition transformer (IT)
Gas pilot vent valve (GPVV) - if provided
Flame Detector Circuit
Flame detector (FD)
Main fuel valve circuit
Main gas valve (MGV)
Main gas vent valve (MGVV) - if provided
Oil valve (OV)
Main fuel valve light (FVL)
