Clevo E4120 - Changing the Optional LCD Back Covers

Upgrading The Computer
6 - 12 Changing the Optional LCD Back Covers
6
Changing the Optional LCD Back Covers
If your purchase option includes the specially designed LCD back cover option, then
follow the instructions below to change the covers (note these covers are not appli-
cable to all models in this series - consult your service center for details).
1. Open the LCD and carefully remove the rubber screw covers & and set
them aside.
2. Remove screws
& from the front cover.

Rubber Screw
Covers
After removing the rub-
ber screw covers,
place them on a clean
dry surface (or attach
them to the front cover
itself) in order to pre-
vent loss of adhesive.
Figure 6 - 10
Removing the
Covers & Screws
1
2
3
4
1
3
2
4
