Clevo E4120 - Ports and Jacks

System Map: Front & Left Views 1 - 11
Quick Start Guide
1
System Map: Front & Left Views
Figure 1 - 4
Front & Left Views
1. LED Power Indica-
tors (see
Table 1 -
1, on page 1 - 7)
2. DC-In Jack
3. External Monitor
Port
4. RJ-45 LAN Jack
5. HDMI-Out Port
6. 2 * USB 2.0 Ports
7. Vent/Fan Intake/
Outlet
8. *ExpressCard 34
Slot (
Optional )
9. Multi-in-1 Card
Reader
* Note the ExpressCard
Slot is a factory option for
certain computer models
in this series only.
2
7
4
1
6
3

Multi-In-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / RSMMC
SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible
MS (Memory Stick) / MS Pro / MS Duo
9
6
8
5
