Upgrading The Computer
6 - 14 Changing the Optional LCD Back Covers
6
5. Align the replacement cover with the dotted line as illustrated below (and as
marked on the cover).
6. Slide the cover forward until it clicks firmly into place .
7. Run your hands around the sides and front of the cover to make sure it is firmly
aligned in place (carefully press down to make sure the fit is secure).
8. Replace the screws and rubber covers (see Figure 6 - 10 on page 6 - 12).
Figure 6 - 13
Replacing the LCD
Back Cover
