Figure 6
Bottom & Rear Views
1. Vent
2. RJ-45 LAN Jack
3. Speakers
1
1
1
Overheating
To prevent your computer from overheating make sure nothing blocks any vent while the
computer is in use.
Bottom Cover Removal Warning
Do not remove any cover(s) and/or screw(s) for the purposes of device upgrade as this
may violate the terms of your warranty.
If you need to replace/remove the hard disk/RAM etc., for any reason, please contact
your distributor/supplier for further information.
1
1
2
1
1
1
2
Models A & B
Model C
3
3
1
1
3
3
