Clevo PA71HS User Manual

Disassembly
Removing the LCD Module 2 - 21
2.Disassembly
10. Remove the screws - (Figure 12c).
11. Remove the LCD panel (Figure 16b).
12. Reverse the process to install a new LCD panel.
38
41
42
h.
g.
42
38 39
41 40

42. LCD Panel
•4 Screws
Figure 16
LCD Module
Removal (cont’d)
g. Remove the screws.
h. Remove the LCD panel.
