Unit Start-Up Procedure
If performance during any mode appears abnormal, refer to
the DXM2 section or troubleshooting section of this manual.
NOTE: To obtain maximum performance, the air coil should
be cleaned before start-up. A 10% solution of dishwasher
detergent and water is recommended.
Unit Operating Conditions
Table 12: Water Temperature Change Through
Heat Exchanger
9 - 12
20 - 26
4 - 8
10 - 17
Model GPM
Pressure Drop (psi)
30°F 50°F 70°F 90°F
026
4.0
6.0
7.0
8.0
1.5
3.1
4.1
5.1
1.3
2.6
3.4
4.3
1.1
2.3
3.0
3.8
1.0
2.1
2.7
3.4
038
4.0
6.0
8.0
9.0
1.2
2.6
4.5
5.7
1.0
2.5
4.2
5.2
0.8
2.3
4.0
4.8
0.6
2.1
3.7
4.4
049
5.5
8.3
11.0
12.0
1.1
2.2
3.9
4.5
0.9
2.1
3.6
4.2
0.8
2.0
3.2
3.8
0.7
1.8
3.1
3.5
064
7.0
10.5
14.0
15.0
0.5
1.9
3.9
4.8
0.3
1.8
3.5
4.3
0.2
1.7
3.2
3.9
0.1
1.6
2.9
3.5
072
7.5
11.3
15.0
17.0
1.7
3.9
6.9
8.9
1.5
3.4
6.0
7.7
1.3
3.0
5.4
6.9
1.3
2.8
5.0
6.5
Table 11: TE Coax Water Pressure Drop
