Blower Performance Data – TSM12
Table 5b
All data is presented as lowest of nameplate voltage.
All data is shown wet coil with clean 1” lter.
All data is ran at 80°F DB and 67°F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
Denotes Operation not recommended.
External Static Pressure (in. wg)
PSC - Low Static
Speed Tap 0.0 0.1 0.2 0.3
Low
RPM 760
Power (W) 61
CFM 300
Medium
RPM 830 930
Power (W) 74 69
CFM 340 320
High
RPM 1030 1090 1120
Power (W) 90 85 79
CFM 450 420 360
ECM - Constant Torque
Speed Tap 0.0 0.1 0.2 0.3
1
RPM 800
Power (W) 29
CFM 320
2
RPM 870 960 1050
Power (W) 40 44 48
CFM 360 340 310
3
RPM 960 1040 1130 1220
Power (W) 59 63 67 71
CFM 410 390 370 350
4
RPM 1030 1110 1190 1280
Power (W) 78 82 87 91
CFM 450 430 420 400
ECM - Constant Volume
CFM 0.0 0.1 0.2 0.3
300
RPM 760 890 1040 1170
Power (W) 29 38 48 58
350
RPM 850 980 1100 1220
Power (W) 40 50 62 73
400
RPM 940 1060 1170 1280
Power (W) 52 65 79 92
450
RPM 1030 1140 1230 1330
Power (W) 73 87 101 115
500
RPM 1120 1220
Power (W) 97 111
