ClimateMaster Tranquility TSM Series - Coax Water Pressure Drop

CLIMATEMASTER WATER-SOURCE HEAT PUMPS
TSM/TSL Vertical Stack
Rev.: January 18, 2021
ClimateMaster Water-Source Heat Pumps
72
Coax Water Pressure Drop
Model GPM
Pressure Drop, PSI PD Added for
Add for MWV
30°F 50°F 70°F 90°F
TSM/L09
1.1 1.2 1.0 0.8 0.7 0.7
1.7 2.7 1.9 1.8 1.6 1.6
2.3 4.5 3.1 2.9 2.8 2.6
TSM/L12
1.5 2.1 1.5 1.4 1.3 1.3
2.3 4.3 3.1 2.9 2.8 2.6
3.0 7.0 5.1 4.8 4.6 4.4
TSM/L15
1.9 0.6 0.4 0.4 0.3 0.3
2.8 1.4 0.9 0.8 0.7 0.7
3.8 2.3 1.4 1.3 1.2 1.1
TSM/L18
2.3 0.6 0.4 0.4 0.4 0.3
3.4 1.6 1.1 1.0 0.9 0.9
4.5 2.8 2.0 1.8 1.6 1.5
TSM/L24
3.0 1.0 0.7 0.7 0.6 0.6
4.5 2.1 1.5 1.4 1.2 1.2
6.0 3.6 2.4 2.2 2.1 1.9
TSM/L30
3.8 1.3 1.0 0.9 0.8 0.8
5.6 2.9 2.0 1.9 1.8 1.7
7.5 5.0 3.4 3.2 3.1 2.8
TSM/L36
4.5 1.8 1.4 1.3 1.1 1.0
6.8 3.6 2.8 2.5 2.2 2.0
9.0 5.9 4.5 4.0 3.6 3.3
