Blower Performance Data – TSM09
Table 5a
External Static Pressure (in. wg)
PSC - Low Static
Speed Tap 0.0 0.1 0.2 0.3
Low
RPM 760 870
Power (W) 59 54
CFM 290 270
Medium
RPM 890 940 1000
Power (W) 71 66 61
CFM 350 310 270
High
RPM 990 1060 1080 1100
Power (W) 85 80 75 69
CFM 400 370 310 240
ECM - Constant Torque
Speed Tap 0.0 0.1 0.2 0.3
1
RPM 680
Power (W) 20
CFM 250
2
RPM 760 870
Power (W) 27 30
CFM 290 270
3
RPM 930 1000 1100 1180
Power (W) 43 47 51 54
CFM 370 340 320 290
4
RPM 1010 1070 1160 1240
Power (W) 54 58 62 66
CFM 410 380 360 330
ECM - Constant
Volume
CFM 0.0 0.1 0.2 0.3
250
RPM 680 830 960 1120
Power (W) 22 30 38 47
300
RPM 780 920 1060 1200
Power (W) 29 38 48 58
350
RPM 890 1020 1160 1280
Power (W) 40 50 62 73
400
RPM 990 1110 1240 1340
Power (W) 52 65 79 92
All data is presented as lowest of nameplate voltage.
All data is shown wet coil with clean 1” lter.
All data is ran at 80°F DB and 67°F WB.
CFM Tolerance is 7%.
RPM/Watt Tolerance 10%.
Denotes Operation not recommended.
