Accessory Nomenclature, Cont’d.
Supply Air Grille
A 8 1 6 G A 1 2 0 6S S
1 2 3 4 5 9 10 11 127 8
SUPPLY AIR GRILLE
MATERIAL & COLOR
DIMENSIONS
C = DOUBLE DEFLECTION
w/OPPOSED DAMPER
GRILLE DEFLECTION
SS = BRUSHED ALUMINUM
A = SINGLE DEFLECTION
B = DOUBLE DEFLECTION
6
1206 = 12"W x 6"H
SP = PAINTED ALUMINUM, POLAR ICE
SW = PAINTED ALUMINUM, BRIGHT WHITE
O
13
SPECIAL OPTIONS
O = STANDARD
Always "O" Unless Special Option
Quoted From Factory
A
14
REVISION LEVEL
A = CURRENT
Cabinet Stands (Ship loose in bulk for eld attachment)
0
5
Accessory
Cabinet Stand
TSM/TSL
01
7
0
8
0
10
0
9
CABINET SIZE
ACST
1 2 3 4
ISO PAD
FUTURE USE
FUTURE USE
0
11
0
12
B
13
FUTURE USE
FUTURE USE
REVISION
HEIGHT
6
0 = 17” x 17”
1 = 19” x 19”
2 = 24” x 24”
3 = 17” x 20”
4 = 19” x 22”
5 = 24” x 27”
01 = 1”
03 = 3”
02 = 2”
04 = 4”
05 = 5”
06 = 6”
07 = 7”
08 = 8”
09 = 9”
10 = 10”
11 = 11”
12 = 12”
13 = 13”
0 = STANDARD
0 = STANDARD (NO ISO PAD)
1 = ISO PAD
0 = STANDARD
0 = STANDARD
0 = STANDARD
B = CURRENT REVISION
