climatemaster.com
21
Tranquility
®
20 (TE) Series
Rev.: June 5, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Electrical – Line Voltage, Cont’d.
Table 4b: Tranquility
®
20 (TS) Series Electrical Data - (PSC High Static Motor & ClimaDry
®
)
All TS Units with High Static PSC Fan Motor TS (H.S. PSC) Units
TS Units with H.S. PSC Fan Motor and
ClimaDry
®
Model
Voltage
Code
Rated
Voltage
Voltage
Min/Max
Compressor
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
Reheat
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
QTY RLA LRA
018
G 208/230/60/1 197/254 1 9.0 48.0 1.1 10.1 12.4 20 0.8 10.9 13.2 20
E 265/60/1 239/292 1 8.4 40.0 0.9 9.3 11.4 15 0.7 10.0 12.1 20
024
G 208/230/60/1 197/254 1 13.5 58.3 1.8 15.3 18.7 30 0.8 16.1 19.5 30
E 265/60/1 239/292 1 9 54.0 1.4 10.4 12.7 20 0.7 11.1 13.4 20
H 208/230/60/3 197/254 1 7.1 55.4 1.8 8.9 10.7 15 0.8 9.7 11.5 15
F* 460/60/3* 414/506 1 3.5 28.0 1 4.5 5.4 15 0.7 5.2 6.1 15
030
G 208/230/60/1 197/254 1 12.8 64.0 2.2 15.0 18.2 30 0.8 15.8 19.0 30
E 265/60/1 239/292 1 10.9 60.0 1.7 12.6 15.3 25 0.7 13.3 16.0 25
H 208/230/60/3 197/254 1 8.3 58.0 2.2 10.5 12.6 20 0.8 11.3 13.4 20
F* 460/60/3* 414/506 1 5.1 28.0 1.0 6.1 7.4 15 0.7 6.8 8.1 15
036
G 208/230/60/1 197/254 1 16.0 77.0 2.2 18.2 22.2 35 0.8 19.0 23.0 35
E 265/60/1 239/292 1 12.2 72.0 1.7 13.9 17.0 25 0.7 14.6 17.7 25
H 208/230/60/3 197/254 1 10 71.0 2.2 12.2 14.7 25 0.8 13.0 15.5 25
F* 460/60/3* 414/506 1 4.7 38.0 1.0 5.7 6.9 15 0.7 6.4 7.6 15
042
G 208/230/60/1 197/254 1 16.7 79.0 2.7 19.4 23.6 35 0.8 20.2 24.4 40
E 265/60/1 239/292 1 13.5 72.0 2.9 16.4 19.8 30 0.7 17.1 20.5 30
H 208/230/60/3 197/254 1 10.4 73.0 2.7 13.1 15.7 25 0.8 13.9 16.5 25
F* 460/60/3* 414/506 1 5.8 38.0 1.7 7.5 9.0 15 0.7 8.2 9.7 15
N 575/60/3 518/633 1 3.8 36.5 1.4 5.2 6.2 15 N/A N/A N/A N/A
048
G 208/230/60/1 197/254 1 21.8 117.0 2.6 24.4 29.9 50 1.1 25.5 31.0 50
H 208/230/60/3 197/254 1 13.7 83.1 2.6 16.3 19.7 30 1.1 17.4 20.8 30
F* 460/60/3* 414/506 1 6.2 41.0 1.8 8.0 9.6 15 1.3 9.3
10.9 15
N 575/60/3 518/633 1 4.8 33.0 1.4 6.2 7.4 15 N/A N/A N/A N/A
060
G 208/230/60/1 197/254 1 26.4 134.0 4.0 30.4 37.0 60 1.1 31.5 38.1 60
H 208/230/60/3 197/254 1 16 110.0 4.0 20.0 24.0 35 1.1 21.1 25.1 40
F* 460/60/3* 414/506 1 7.8 52.0 2.6 10.4 12.4 15 1.3 11.7 13.7 20
N 575/60/3 518/633 1 5.7 38.9 1.5 7.2 8.6 15 N/A N/A N/A N/A
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with ClimaDry® require a four wire power supply with neutral. Reheat pump is rated 265 vac and is wired between one hot
leg and neutral.
