ClimateMaster Water-Source Heat Pumps
6
Unit Physical Data
Tranquility
®
20 Single-Stage (TS) Series (60Hz)
Model 006 009 012 018 024 030 036 042 048 060 070
Compressor (1 Each) Rotary Scroll
Factory Charge
HFC-410A (oz) [kg]
24 [0.68] 32 [0.91] 34 [0.96] 50 [1.13] 41 [1.16] 41 [1.16] 48 [1.36] 68 [1.93] 68 [1.93] 136 [3.86] 141 [4.0]
ECM Fan Motor & Blower
Blower Wheel Size
(dia x w) - (in) [mm]
N/A N/A N/A
9 x 7
[229 x 178]
9 x 7
[229 x 178]
9 x 7
[229 x 178]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
PSC Fan Motor & Blower (3 Speeds)
Blower Wheel Size
(dia x w) - (in) [mm]
6 X 5
[152 X 127]
6 X 5
[152 X 127]
6 X 5
[152 X 127]
9 x 7
[229 x 178]
9 x 7
[229 x 178]
9 x 7
[229 x 178]
10 x 10
[254 x 254]
10 x 10
[254 x 254]
10 x 10
[254 x 254]
11 x 10
[279 x 254]
11 x 10
[279 x 254]
Water Connection Size
FPT (in)
1/2” 1/2” 1/2” 3/4” 3/4” 3/4” 3/4” 1” 1” 1” 1”
HWG Connection Size
FPT (in)
N/A N/A N/A 1/2” 1/2” 1/2” 1/2” 1/2” 1/2” 1/2” 1/2”
Coax Volume
Volume (US Gallons)
[liters]
0.17 [0.64] 0.29 [1.10] 0.45 [1.70] 0.56 [2.12] 0.76 [2.88] 0.76 [2.88] 0.92 [3.48] 1.24 [4.69] 1.24 [4.69] 1.56 [5.91] 1.56 [5.91]
Vertical Up ow/Down ow
Air Coil Dimensions
(h x w) - (in) [mm]
16 x 16
[406 x 406]
Up ow
Only
16 x 16
[406 x 406]
Up ow
Only
16 x 16
[406 x 406]
Up ow
Only
24 x 20
[610 x 508]
28 x 20
[711 x 508]
28 x 20
[711 x 508]
28 x 25
[711 x 635]
32 x 25
[813 x 635]
32 x 25
[813 x 635]
36 x 25
[914 x 635]
36 x 25
[914 x 635]
Standard Filter - 1”
[25.4mm]
Throwaway,
qty (in) [mm]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
24 x 24
[610 x 610]
28 x 24
[711 x 610]
28 x 24
[711 x 610]
28 x 30
[711 x 762]
2 - 16 x 30
[2 - 406 x 762]
2 - 16 x 30
[2 - 406 x 762]
1 - 16 x 30;
1 - 20 x 30
[1 - 406 x 762;
1 - 508 x 762]
1 - 16 x 30;
1 - 20 x 30
[1 - 406 x 762;
1 - 508 x 762]
Weight - Operating,
(lbs) [kg]
136 [62] 156 [71] 160 [73] 257 [117] 266 [121] 268 [122] 327 [148] 414 [188] 416 [189] 441 [200] 443 [201]
Weight - Packaged,
(lbs) [kg]
146 [66] 166 [75] 170 [77] 267 [121] 276 [125] 278 [126] 337 [153] 424 [192] 426 [193] 451 [205] 453 [205]
Horizontal
Air Coil Dimensions
(h x w) - (in) [mm]
16 x 16
[406 x 406]
16 x 16
[406 x 406]
16 x 16
[406 x 406]
18 x 27
[457 x 686]
18 x 31
[457 x 787]
18 x 31
[457 x 787]
20 x 35
[508 x 889]
20 x 40
[508 x 1016]
20 x 40
[508 x 1016]
20 x 45
[508 x 1143]
20 x 45
[508 x 1143]
Standard Filter - 1”
[25.4mm]
Throwaway,
qty (in) [mm]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
16 x 20
[406 x 508]
2 - 18 x 18
[2 - 457 x
457]
2 - 18 x 18
[2 - 457 x
457]
2 - 18 x 18
[2 - 457 x 457]
1 - 12 x 20;
1- 20 x 25
[1 - 305 x 508;
1 - 508 x 635]
1 - 18 x 20;
1 - 20 x 24
[1 - 457 x 508;
1 - 508 x 610]
1 - 18 x 20;
1 - 20 x 24
[1 - 457 x 508;
1 - 508 x 610]
2 - 20 x 24
[2 - 508 x 610]
2 - 20 x 24
[2 - 508 x 610]
Weight - Operating,
(lbs) [kg]
136 [62] 156 [71] 160 [73] 257 [117] 266 [121] 268 [122] 327 [148] 414 [188] 416 [189] 441 [200] 443 [201]
Weight - Packaged,
(lbs) [kg]
146 [66] 166 [75] 170 [77] 267 [121] 276 [125] 278 [126] 337 [153] 424 [192] 426 [193] 451 [205] 453 [205]
Notes:
All units have TXV expansion device and 1/2” & 3/4” electrical knockouts.
575 volt motors are two speed.
For units with ClimaDry
®
II option add 66lbs (30kg) to weights.
Unit Maximum Water Working Pressure
Options Max Pressure PSIG [kPa]
Base Unit 500 [3,447]
Internal Secondary Pump (ISP)
145 [999]
ClimaDry
®
145 [999]
Internal Motorized Water Valve (MWV)
300 [2,068]
Internal Auto Flow Valve
300 [2,068]
Use the lowest maximum pressure rating when multiple options are combined.
