Tranquility
®
20 (TE) Series
Rev.: June 5, 2020
THE SMART SOLUTION FOR ENERGY EFFICIENCY
Unit Operating Conditions
Model
U.S.
GPM
l/s l/m
Pressure Drop, psi [kPa]*
30ºF [-1ºC] 50ºF [10ºC] 70ºF [21ºC] 90ºF [32ºC]
006
1.0 0.063 4 0.3 [2.1] 0.3 [2.1] 0.2 [1.4] 0.2 [1.4]
1.5 0.095 6 1.6 [11.0] 1.4 [11.0] 1.2 [11.0] 1.0 [11.0]
2.0 0.126 8 3.0 [20.7] 2.6 [17.9] 2.2 [15.2] 1.8 [12.4]
009
1.4 0.088 5 0.8 [5.5] 0.7 [4.8] 0.6 [4.1] 0.6 [4.1]
2.1 0.132 8 1.5 [10.3] 1.4 [9.7] 1.2 [8.3] 1.1 [7.6]
2.8 0.177 11 2.7 [18.6] 2.4 [16.5] 2.2 [15.2] 1.9 [13.1]
012
1.8 0.114 7 0.6 [4.1] 0.5 [3.4] 0.4 [2.8] 0.3 [2.1]
2.6 0.164 10 2.1 [14.5] 1.9 [13.1] 1.6 [11.0] 1.4 [9.7]
3.5 0.221 13 3.8 [26.2] 3.4 [23.4] 3.0 [20.7] 2.6 [17.9]
018
2.8 0.176 11 0.7 [4.8] 0.5 [3.4] 0.3 [2.1] 0.2[1.4]
4.1 0.258 15 2.1 [14.5] 1.7 [11.7] 1.4 [9.7] 1.1 [7.6]
5.5 0.347 21 3.5 [24.1] 2.8 [19.3] 2.4 [16.6] 2.0 [13.8]
024
3.0 0.189 11 1.2 [8.0 ] 0.3 [2.4] 0.2 [1.1 0.1 [.69]
4.5 0.284 17 1.9 [13.2] 1.0 [7.2] 0.7 [4.7] 0.5 [3.4]
6.0 0.379 23 2.0 [13.8] 1.4 [9.7] 1.2 [7.8] 1.0 [6.8]
030
3.8 0.240 14 0.9 [5.9] 0.8 [5.6] 0.8 [5.2] 0.7 [5.0]
5.6 0.353 21 1.6 [11.0] 1.4 [9.7] 1.3 [9.2] 1.3 [8.8]
7.5 0.473 28 2.5 [17.5] 2.2 [15.2] 2.1 [14.3] 2.0 [13.7]
036
4.5 0.284 17 1.2 [8.0] 0.8 [5.6] 0.9 [6.1] 0.8 [5.6]
6.8 0.430 26 2.4 [16.5] 1.9 [13.4] 1.8 [12.4] 1.7 [11.6]
9.0 0.568 34 4.0 [27.6] 3.2 [22.2] 3.0 [20.6] 2.8 [19.4]
042
5.5 0.347 21 1.0 [7.0] 0.9 [6.1] 0.8 [5.8] 0.8 [5.6]
8.3 0.524 31 2.2 [15.2] 1.9 [12.8] 1.8 [12.3] 1.8 [12.4]
11.0 0.694 42 3.8 [25.8] 3.4 [23.1] 3.2 [22.1] 3.1 [21.4
048
6.0 0.379 23 1.1 [7.6] 0.9 [5.9] 0.7 [5.2] 0.8 [5.4]
9.0 0.568 34 2.3 [15.9] 1.8 [12.5] 1.8 [12.7] 1.8 [12.3]
12.0 0.757 45 3.9 [26.9] 3.2 [22.0] 3.2 [21.9] 3.0 [21.0]
060
7.5 0.473 28 1.3 [9.1] 0.6 [4.3] 0.5 [3.2] 0.5 [3.4]
11.3 0.713 43 3.5 [24.5] 2.5 [16.9] 2.1 [14.2] 2.0 [13.6]
15.0 0.947 57 6.1 [42.0] 4.7 [32.4] 4.1 [28.2] 3.9 [27.0]
070
9.0 0.568 34 2.7 [18.7] 1.7 [12.0] 1.5 [10.4] 1.6 [10.7]
13.5 0.852 51 5.2 [35.8] 3.8 [26.3] 3.3 [22.8] 3.2 [22.2]
18.0 1.140 68 8.1 [56.0] 6.4 [44.1] 5.7 [39.0] 5.5 [37.6]
Table 9: TS Coax Water Pressure Drop
Model
WPD Adders
GPM PSI FT
018
2.8 0.77 1.77
4.1 1.65 3.80
024
4.0 1.57 3.62
6.0 3.53 8.14
030
4.0 0.69 1.59
6.0 1.55 3.58
036
4.5 0.87 2.02
6.8 1.99 4.60
042
5.5 1.30 3.01
8.3 6.75 15.58
048
6.0 1.55 3.58
9.0 3.49 8.06
060
7.5 1.49 3.45
11.3 3.39 7.82
070
8.3 1.83 4.22
12.4 4.08 9.42
Model Cv MOPD
WPD Adders
GPM PSI FT
006
4.9 150 1.0 0.04 0.10
4.9 150 1.5 0.09 0.22
4.9 150 2.0 0.17 0.38
009
4.9 150 1.4 0.08 0.19
4.9 150 2.1 0.18 0.42
4.9 150 2.8 0.33 0.75
012
4.9 150 1.8 0.13 0.31
4.9 150 2.6 0.28 0.65
4.9 150 3.5 0.51 1.18
018
10.3 125 2.8 0.07 0.16
10.3 125 4.1 0.16 0.37
10.3 125 5.5 0.29 0.66
024
10.3 125 4.0 0.15 0.35
10.3 125 6.0 0.34 0.78
10.3 125 8.0 0.60 1.39
030
10.3 125 4.0 0.15 0.35
10.3 125 6.0 0.34 0.78
10.3 125 8.0 0.60 1.39
036
10.3 125 4.5 0.19 0.44
10.3 125 6.8 0.43 0.99
10.3 125 9.0 0.76 1.76
042
10.3 125 5.5 0.29 0.66
10.3 125 8.3 0.64 1.48
10.3 125 11.0 1.14 2.63
048
10.3 125 6.0 0.34 0.78
10.3 125 9.0 0.76 1.76
10.3 125 12.0 1.36 3.14
060
8.9 125 7.5 0.71 1.64
8.9 125 11.3 1.60 3.69
8.9 125 15.0 2.84 6.56
070
8.9 125 8.3 0.86 1.98
8.9 125 12.4 1.93 4.47
8.9 125 16.5 3.44 7.94
Motorized Water Valve Option Corrections
