CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
20 (TS) Series
Rev.: June 5, 2020
ClimateMaster Water-Source Heat Pumps
20
Electrical – Line Voltage
All TS Units with Standard PSC Motor TS Units (PSC)
TS Units with PSC Fan Motor
and ClimaDry
®
Model
Voltage
Code
Rated
Voltage
Voltage
Min/Max
Compressor
Fan
Motor
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
Reheat
Pump
FLA
Total
Unit
FLA
Min
Circuit
Amp
Max
Fuse/
HACR
QTY RLA LRA
018
G 208/230/60/1 197/254 1 9.0 48.0 1.0 10.0 12.3 20 0.8 10.8 13.1 20
E 265/60/1 239/292 1 8.4 40.0 0.9 9.3 11.4 15 0.7 10.0 12.1 20
024
G 208/230/60/1 197/254 1 13.5 58.3 1.6 15.1 18.5 30 0.8 15.9 19.3 30
E 265/60/1 239/292 1 9 54.0 1.1 10.1 12.4 20 0.7 10.8 13.1 20
H 208/230/60/3 197/254 1 7.1 55.4 1.6 8.7 10.5 15 0.8 9.5 11.3 15
F* 460/60/3* 414/506 1 3.5 28.0 0.9 4.4 5.3 15 0.7 5.1 6.0 15
030
G 208/230/60/1 197/254 1 12.8 64.0 1.8 14.6 17.8 30 0.8 15.4 18.6 30
E 265/60/1 239/292 1 10.9 60.0 1.4 12.3 15.0 25 0.7 13.0 15.7 25
H 208/230/60/3 197/254 1 8.3 58.0 1.8 10.1 12.2 20 0.8 10.9 13.0 20
F* 460/60/3* 414/506 1 5.1 28.0 1.0 6.1 7.4 15 0.7 6.8 8.1 15
036
G 208/230/60/1 197/254 1 16.0 77.0 1.8 17.8 21.8 35 0.8 18.6 22.6 35
E 265/60/1 239/292 1 12.2 72.0 2.0 14.2 17.3 25 0.7 14.9 18.0 30
H 208/230/60/3 197/254 1 10 71.0 1.8 11.8 14.3 20 0.8 12.6 15.1 25
F* 460/60/3* 414/506 1 4.7 38.0 1.0 5.7 6.9 15 0.7 6.4 7.6 15
042
G 208/230/60/1 197/254 1 16.7 79.0 2.2 18.9 23.1 35 0.8 19.7 23.9 40
E 265/60/1 239/292 1 13.5 72.0 1.7 15.2 18.6 30 0.7 15.9 19.3 30
H 208/230/60/3 197/254 1 10.4 73.0 2.2 12.6 15.2 25 0.8 13.4 16.0 25
F* 460/60/3* 414/506 1 5.8 38.0 1.0 6.8 8.3 15 0.7 7.5 9.0 15
N 575/60/3 518/633 1 3.8 36.5 0.8 4.6 5.6 15 N/A N/A N/A N/A
048
G 208/230/60/1 197/254 1 21.8 117.0 2.7 24.5 30.0 50 1.1 25.6 31.0 50
E 265/60/1 239/292 1 16.3 98.0 2.9 19.2 23.3 35 1.3 20.5 24.6 40
H 208/230/60/3 197/254 1 13.7 83.1 2.7 16.4 19.8 30 1.1 17.5 20.9 30
F* 460/60/3* 414/506 1 6.2 41.0 1.7 7.9 9.5 15 1.3 9.0 10.6 15
N 575/60/3 518/633 1
4.8 33.0 1.4 6.2 7.4 15 N/A N/A N/A N/A
060
G 208/230/60/1 197/254 1 26.4 134.0 3.8 30.2 36.8 60 1.1 31.3 37.9 60
H 208/230/60/3 197/254 1 16 110.0 3.8 19.8 23.8 35 1.1 20.9 24.9 40
F* 460/60/3* 414/506 1 7.8 52.0 1.3 9.1 11.1 15 1.3 10.4 12.4 20
N 575/60/3 518/633 1 5.7 38.9 2.2 7.9 9.3 15 N/A N/A N/A N/A
070
G 208/230/60/1 197/254 1 30.8 178.0 4.0 34.8 42.5 70 1.1 35.9 43.6 70
H 208/230/60/3 197/254 1 19.6 138.0 4.0 23.6 28.5 45 1.1 24.7 29.6 45
F* 460/60/3* 414/506 1 8.2 66.1 2.6 10.8 12.9 20 1.3 12.1 14.2 20
N 575/60/3 518/633 1 6.6 55.3 1.5 8.1 9.8 15 N/A N/A N/A N/A
* NEUTRAL CONNECTION REQUIRED! All F Voltage (460 vac) units with ClimaDry® require a four wire power supply with neutral. Reheat pump is rated 265 vac and is wired between one hot
leg and neutral.
Electrical - Line Voltage - All eld installed wiring,
including electrical ground, must comply with the National
Electrical Code as well as all applicable local codes. Refer
to the unit electrical data for fuse sizes. Consult wiring
diagram for eld connections that must be made by
the installing (or electrical) contractor. All nal electrical
connections must be made with a length of exible
conduit to minimize vibration and sound transmission to
the building.
General Line Voltage Wiring - Be sure the available
power is the same voltage and phase shown on the unit
serial plate. Line and low voltage wiring must be done in
accordance with local codes or the National Electric Code,
whichever is applicable.
WARNING! To avoid possible injury or death due to electrical
shock, open the power supply disconnect switch and secure
it in an open position during installation.
CAUTION! Use only copper conductors for eld installed
electrical wiring. Unit terminals are not designed to accept
other types of conductors.
� WARNING! �
� CAUTION! �
Transformer - All 208/230 voltage units are factory wired
for 208 volt. If supply voltage is 230 volt, installer must
rewire transformer. See wire diagram for connections.
Table 4a: Tranquility
®
20 (TS) Series Electrical Data - (PSC Motor & ClimaDry
®
)
