P/N: 57017, Rev. 3 Page 7
2 OVERVIEW
Machining range from 8.8–38" (224–965 mm) diameter and faces from 7.5–42.1"
(191–1,069 mm) are quickly restored to original condition with the CLIMAX
BB6100 Portable Boring Machine.
This modular machine tool shown in Figure 2-1 is dedicated to on-site restoration of
worn internal diameters to precise roundness and dimensional accuracy ready to
accept new bearings, sleeves, shafts, or similar mating parts.
FIGURE 2-1. BB6100 COMPONENTS
Boring/facing counterweight arm
