Page 40 BB6100 Operating Manual
DANGER
Failure to properly torque the four ½-20 x 1-1/4 SHCS (P/N 18225)
to 100 ft-lb (135 Nm) can result in unexpected slippage of the tool
arm which can result in injury or be fatal.
3.13 Adjusting the tool carrier for perpendicularity
The tool carrier is equipped with four set screws that allow you to adjust the slide
arm perpendicularity if required.
3.14 Feedbox assembly
Mount and secure the feedbox (see Section 7 on page 55).
3.15 Feedbox and trip arm set-up
Install the counterweight arm onto the tool carrier
1. Rotate the tool carrier on the bar to allow the counterweight arm to be mounted on the
receiving surface of the tool carrier.
2. Attach the lifting eye onto counterweight arm and install arm.
NOTICE
Always use the lifting eyes when lifting the arms. The rotating lifting
eyes provide the flexibility and safety during setup operations.
3. Using a lifting device such as a crane, lift the counterweight assembly to the arm. Fasten the
counterweight assembly to the arm using the fasteners shown in the exploded views.
Note that you can position the counterweight itself anywhere along the arm as needed to balance the
assembly.
3.16 Mechanical facing head setup
The mechanical facing head assembly requires either a one-piece or the two-piece
tool carrier.
1. Assemble the facing head as necessary. (See the following Facing Head Tool
Range Table and Mechanical Facing Head exploded view drawing to see how the
parts fit together).
2. Mount the facing head onto the tool carrier.
3. Secure a sharpened tool bit in the tool carrier.
