3.9.2 Small bore tool carrier boring head setup
The boring head requires a tool carrier. See “Tool carrier setup” on page 31 for
information.
Number
Component
1
Tool carrier assembly
2
Tool holder
3
1" (25.4 mm) spacer
4
Leading tool holder
5
Trailing tool holder
6
2" (50.18 mm) spacer with slot
7
2" (50.18 mm) spacer no slot
8
6" (152.4 mm) spacer with slot
9
6" (152.4 mm) spacer no slot
10-13
Socket head cap screws (different sizes)
