Climax BB6100 - Spare Parts

P/N 57017, Rev. 3 Page 53
6.2 Spare Parts
Parts listed below include items most frequently required due to wear, loss, or
damage. To avoid unscheduled down time you may want to stock any or all of the
parts listed.
TABLE 5. SPARE PARTS KIT
Where used
P/N
DESCRIPTION
QTY
Boring bar
assembly
22143
NUT LEADSCREW BRG ADJUSTING 3/4 DIA
2
22403
KEY DRIVE 3-1/2 BORING BAR
1
22814
HOIST RING 3/4-10 X 1-1/2 1-3/4 ID 3-1/4 OD 6-
3/8 OAL 5000 LBS SWIVEL
1
22815
SPACER BOLT EYE 1/2 THK
1
Mechanical axial
feed assembly
22409
DIAL FEED
1
14303
ROD STOP
1
Net fit tool carrier
54217
SHOE ADJUSTABLE TOOL CARRIER BB6100
1
54221
SET NUT AXIAL LEAD SCREW 3/4-5 ACME
BB6100
2
14771
SCREW 5/16-18 X 3/4 BHSCS
4
Small bore tool
carrier
22205
NUT AXIAL LEADSCREW
1
22384
WIPER ROD 3.5 ID MOLYTHANE
2
10453
SCREW 3/8-16 X 1-1/4 SHCS
6
Boring/facing arms
45691
ASSY FEEDBOX REVERSE CLUTCH INPUT
1
54178
NUT HALF FACING HEAD BB7100
1
55094
TRIP ARM STEEL 3 INCH
1
Hydraulic power
unit
NA
See the HPU operator manual.
NA
Tooling
79020
BORING HEAD MICRO ADJUST 3/4 INCH
TOOLING (1/2 INCH READY) LARGE BB
1
