Page 34 BB6100 Operating Manual
TIP:
The bar can rotate in either direction. Be sure the tool bits face the
correct direction.
BB6100 Micro adjust boring head tool range table
8.8–40.8" (224–1,036 mm) diameter
Bore range diameter
Number of spacer blocks required
2" (51 mm)
block
4" (102 mm)
block
8" (203 mm)
block
8.8–12.8" (224–325 mm)
0
0
0
12.8–16.8" (325–427 mm)
1
0
0
16.8–20.8" (427–528 mm)
0
1
0
20.8–24.8" (528–630 mm)
1
1
0
24.8–28.8" (623–732 mm)
0
0
1
28.8–32.8" (732–833 mm)
1
0
1
32.8–36.8" (833–935 mm)
0
1
1
36.8–40.8" (935–1036 mm)
1
1
1
