4
INSTALLATION
Please read the installation procedure carefully prior to the actual installation. Consult a professional
installer if you have any issues or concerns with the installation.
1. From the back of CAD15 unit, snap the cradle into the unit.
2. Mount the cradle.
Peel off the backing of the 3M tape on the bottom of the cradle.
Attach the cradle to a desired location, and then press the bottom of the cradle to
permanently secure the cradle and CAD15 unit.
Alter the CAD15’s orientation as necessary by using the adjustable knob of the cradle.
3. Install the supplied DAB antenna; please refer to the section on Antenna Installation.
ATTENTION
We have fully tested the DAB Antenna, if supplied, to work with CAD15. If you use a third
party’s DAB antenna, the performance may suffer.
For CAD15 to work with the active antenna, the antenna power must be set to ON.
CAD15 can also work with a passive antenna; you must set the antenna power to OFF.
Anytime you need to disconnect/connect the antenna from CAD15, please unplug
CAD15 from the cigarette lighter first to avoid possible damage to the antenna.
Damage resulted from incorrect installation of the antenna is not covered by the warranty.
4. Secure the antenna cable on the back of the CAD15 unit, so that it won’t fall off, and then
plug the antenna cable to CAD15.
Fit the antenna cable tightly into the gap on the back of the CAD15 unit leaving about
10cm of slack to the end of the antenna cable.
Plug the end connector of the antenna cable into the antenna connector located on the
side panel of CAD15.
5. Secure by fitting the supplied cigarette-lighter power cable into the gap on the back of the
CAD15 unit, and then plug the cable connector into the power jack located at the side panel
of CAD15.
6. Plug the cigarette-lighter power plug into the cigarette lighter, this will also power on CAD15.
