M08F40N15-02 CSRN-XHE2 15.2-44.4 19
7.13 ECO mode
The air ow supply remains constant at varied heat loads and is shutdown when setpoint is fullled.
To further increase the energy savings in this condition, it is also possible to set less demanding operation setpoints for the unit in respect to
the standard mode.
This function is indicated for the thermal maintenance of the served area in case it is temporarily not used, which can for example occur at
night.
The ECO mode can be activated:
t
Manually: P05 Enable EcoMode = 1
t
Automatically by means supervision system
Example in cooling mode:
time
time
time
SetCool
SetECOCool
TimeEco
TimeTestEco
Fan
Compressor
Air return temp
P02 Setpoint ECO Heat
P03 Setpoint ECO Cool
P04 Enable EcoMode
P18 TimeEco
P19 TimeTestEco
TimeEco
TimeEco
On
Off
On
Off
Set
ECO
Heat
Set
ECO
Cool
Set
Heat
Set
Cool
Return
air
temp
7.14 Set-point automatic compensation
The set changes automatically according to the outside temperature.
Even the operating mode changes automatically according to the outside temperature.
The variation is dened by the climatic curve.
P16
Setpoint
Outdoor temp.
P17
P15
P09
P14
P10 P11 P13 P12
Setpoint
COOL
Setpoint
HEAT
DeadZone
5°C 20°C 24°C 35°C
28°C
22°C
21°C
19°C
example
P05 EnableAutoSet = 1
